The original hogarthian reg set up

Discussion in 'Hogarthian Diving' started by DanaHunt, Jan 4, 2019.

  1. DanaHunt

    DanaHunt DIR Practitioner

    # of Dives: I just don't log dives
    Location: Watertown, NY
    345
    103
    43
    I read it was a pair of conshelfs. Anyone have any information on hose routing and lengths ? Was it din or yoke ?

  2. kensuf

    kensuf Cave Instructor

    1,951
    2,419
    113
    LOL. Go old school or go home, eh?

    The "original" Hogarthian Manifold was the Scubapro Yoke manifold with barrel o-rings

    Conshelf XIV's.

    7' hose was on the right post, angled down, drysuit (if needed) was also on the right post, at about the 4 o'clock.

    Middle post was the short hose (20 or 22"?), wing inflator (sized as needed) and pressure gauge. Yes, I said middle post, there was no left post and no isolator.


    Attached Files:

  3. DanaHunt

    DanaHunt DIR Practitioner

    # of Dives: I just don't log dives
    Location: Watertown, NY
    345
    103
    43
  4. kensuf

    kensuf Cave Instructor

    1,951
    2,419
    113
    BTW, if you can get your hands on The Art of Safe Cave Diving, Chapter 5 is about the Hogarthian Gear configuration and was written by Bill Gavin. It's actually more of a mindset article and less of an equipment configuration article, but it'll get you thinking.

    ericfine50 and northernone like this.
  5. DanaHunt

    DanaHunt DIR Practitioner

    # of Dives: I just don't log dives
    Location: Watertown, NY
    345
    103
    43
    Cool. I've read that hogarthian configuration is intended to be evolving and it was generally ok to configure changes as long as they are well thought out.

    rjack321 likes this.
  6. tbone1004

    tbone1004 ScubaBoard Supporter ScubaBoard Supporter

    # of Dives: I'm a Fish!
    Location: Greenville, South Carolina, United States
    15,610
    6,927
    113
    @kensuf aren't you supposed to be lounging on the beach?

    @DanaHunt of importance for the evolution, if you look at Bill's current setup, it is not what you see from the DIR crowd on their doubles

    rjack321 and Caveeagle like this.
  7. DanaHunt

    DanaHunt DIR Practitioner

    # of Dives: I just don't log dives
    Location: Watertown, NY
    345
    103
    43
    Tell me more

  8. tbone1004

    tbone1004 ScubaBoard Supporter ScubaBoard Supporter

    # of Dives: I'm a Fish!
    Location: Greenville, South Carolina, United States
    15,610
    6,927
    113
    the two big ones on the reg configuration
    often no isolator-some have them, others don't. Obviously non-isolating crossbars are hard to find, but a few of his are still straightbar
    inflator on the left post


    Compressor likes this.
  9. DanaHunt

    DanaHunt DIR Practitioner

    # of Dives: I just don't log dives
    Location: Watertown, NY
    345
    103
    43
    Inflator on left post because it would be easier to recognize a roll off before it was too late?

  10. tbone1004

    tbone1004 ScubaBoard Supporter ScubaBoard Supporter

    # of Dives: I'm a Fish!
    Location: Greenville, South Carolina, United States
    15,610
    6,927
    113
    I believe so. @kensuf may know better
